Detail:
PetroChina KunLun HM Anti-wear Hydraulic Oil(High Pressure)
Quality Level:
GB 11118.1; ISO11158,DIN 51524-2; Denison HF-0/HF-1/HF-2;Eaton 03-401-2010; Cincinnati P68/P70/P69.
Scope of Application:
1. Hydraulic system working temperature 0-80℃, working pressure can be higher than 14Mpa
2. Can not be used on hydraulic system which contain copper or silver components.
Data Sheet
| ITEMS |
INDEX |
| ISO Viscosity Grade |
HM32 |
HM46 |
HM68 |
Test Method |
| Viscosity at 40ºC,mm2/s |
32.21 |
46.14 |
65.77 |
GB/T 265 |
| Viscosity index |
99 |
100 |
97 |
GB/T 2541 |
| Pour Point,ºC |
-15 |
-12 |
-12 |
GB/T 3535 |
| Min Demulsibility at 54ºC |
15 |
15 |
10 |
GB/T 7305 |
| Foam stability, ML/ML |
|
|
|
GB/T 12579 |
| 24ºC |
20/0 |
30/0 |
35/0 |
| 93ºC |
20/0 |
20/0 |
20/0 |
| then 24ºC |
20/0 |
25/0 |
20/0 |
| Grade of Copper Corrsion(100ºC,3h) |
1A |
1A |
1A |
GB/T 5096 |
| Liquid phase rust test |
None |
None |
None |
GB/T 11143B |
| Oxidation stability(2.0mgKOH/g), h |
>1500 |
>1500 |
>1500 |
GB/T 12581 |
| FZG Bearing capacity of gear machine test, |
11 |
11 |
12 |
GB/T 0306 |
